Coating Thickness Gauge CM-8826FN

Features:

* Two measuring methods: magnetic induction (F) and eddy current (N)

* Two measurement mode: Single and Continuous（Notice：Continuous mode is convenient to measure the coating thickness of curved objects and tiny objects.）

* Metric/imperial system selectable.

* Manual or automatic shut down.

* Auto memory of calibration value,and auto recognize the substrate.

* Operation process have buzzing reminder,while no buzzing in continuous mode.

* Use “USB data output” and “RS-232 data output” to connect with PC.

* Provide “Bluetooth ™ data output” choice.

* Separate Type can provide several type probe, measure can be more flexibility.

Details:

Measuring Range 0~1250 um / 0~50 mil

Resolution 0.1 um / 1 um

Min. Radius Workpiece F Type: convex 1.5 mm / concave 25 mm NF Type: convex 3 mm / concave 50 mm

Min. Measuring Area 6 mm

Min. Sample Thickness 0.3 mm

Accuracy ± 1~3%n or ± 2.5 um

Auto Power Off

Metric / Imperial Convertible

Battery Indicator Low Battery Indicator

Operating Conditions Temp. 0~40 °C, Humidity: 10~90 %RH

Power Supply 4 x 1.5 V AAA (UM-4) Battery

Dimensions 126 x 65 x 27 mm

Weight 81 g (Not Including Batteries

Standard Accessories:

1. Main Unit

2. Probe (F Type / NF Type)

3. Calibration Base Set (F Type / NF Type) CTG-BS

4. Calibration Foils CTG-CF (1 set, 4 pieces)

5. Carrying Case

6. Operation Manual
